SpoolPro™ Foot Pedal for Automated Wire Spooler

SpoolPro™ Foot Pedal (Optional Start / Stop Accessory)

The SpoolPro™ Foot Pedal is a foot-operated start/stop control for the SpoolPro Automated Wire Spooler. It gives operators hands-free control at the machine, freeing both hands for handling wire and cable during high-repetition spooling work. When fitted, the foot pedal replaces the standard remote control.

A protective metal shroud surrounds the pedal to help prevent accidental activation and shield it from knocks on a busy shop floor. The 6 ft cable and 6-position circular connector make it a plug-and-play addition to your existing SpoolPro setup, with no tools or rewiring needed.

Key features

• Hands-free start/stop control at the operator station
• Guarded metal shroud reduces unintended activation
• Normally Closed (NC) momentary footswitch circuit
• 6 ft cable with 6-position circular connector
• Plug-and-play installation, replaces the standard remote control
• Ideal for high-repetition spooling tasks where foot control is preferred

Specifications
