Delivery Information: Please note that there is a 48 hour shipping time on this product.
This heat-shrinkable tubing is flame-retardant, halogen-free, and easy to apply. Suitable for both fluid and electrical systems (including automotive and mass transit), it offers reliable performance and is available in a range of sizes and lengths to suit your needs.
Product Features
- Flame Retardant
- Halogen-free (also no lead, chromium, cadmium, or mercury)
- Flexible yet durable polyolefin
- Simple Installation
- Cut to length
- UL 600V and F mark certifications
Technical Information
| Shrink Temperature | 90°C (194°F) |
| Temperature Range | -40° to +125°C (-40° to 257°F) |
| Radial Shrinking Ratio | > 50% |
| Longitudinal Change | > 5% |
| Tensile Strength | > 10.4 MPa (1,508 psi) |
| Ultimate Elongation | > 200% |
| Aging in Circulating Air-Oven | 158.0 + 1.0℃, 168 hours |
| After Aging | > 7.3 MPa (1,059) |
| Tensile Strength and Ultimate Elongation | > 100% |
| Volume Resistivity | > 1,014 W.cm |
| Dielectric Strength | > 15 KV/mm |
| Flammability | VW-1 |
| Concentricity | >65 |
